6090 pcb drilling milling machine/pcb protypes making machine/cnc pcb router/pcb cnc engraver JCUT-6090
price: FOB Qingdao
payment term: T/T in advance
Main technical parameter:
Machined surface: Single/double
Worktable board (mm):600X900
Max.Speed:8000mm/min
Working speed: 0-4000mm/min
Working accuracy: 6-8mil
Least line diameter and least line spacing:6 -8mil
Drilling depth: 0.02 ~ 3mm
Drilling diameter: 0.4 ~ 3.175mm
Drilling holes: 40-100/min
Repeat Accuracy: 0.025mm
The least error of Data control drill less than 1mil (0.015mm)
Operation system: WIN2000/XP /VISTA
Means of communication: PCI or RS232
Function Request: Protel PCB document can be directly put in.(gerber)
Spindle speed: 24000rpm
Spindle power: 800W
Power supply: 110v60hz/220v50hz
Free parts along with the
machine: Controlling Box, Controlling Card and Software, Water Tank, Water-cooling Pump, Engraving Tools, Data Wire, Power Line, Brush, Clamp, and Spanner.
